N2XY
N2XY are unarmoured power and control cables used for electricity supply in Low Voltage (LV) installation systems with a voltage rating of 600/1000V. These cables can be used for fixed installation in buildings - fixed on cable trays, in free air, within conduits, or in walls – or for underground use in direct burial and in damp environments where there is no risk of mechanical damage.
DOWNLOAD TECHNICAL DATA SHEET
CONDUCTOR
Round Stranded Annealed Copper Wires (rs)
INSULATION
Cross-linked Polyethylene (XLPE)
Colour : Yellow, Blue, Black, Yellow-Green
OUTER SHEATH
Polyvinyl Chloride (PVC)
Colour : Black
Applications
- For fixed installation in buildings
- For direct burial without mechanical stress
Reaction to Chemical
Not specified.
Reaction to fire
Flame Retardant; IEC-60332-1
Maximum service temperature
90°C.
Packaging
Haspel / Cut on demand.
Standards
- SNI IEC 60502-1
